Vertical elevator stage
The OES AZ60-A low-profile, wedge-type motorized vertical elevator stage has 6 crossed roller guides and an 8mm-diameter lead ball screw for straight vertical motion, parallelism and repeatability. Constructed of black-anodized aluminum alloy with a double-ended shaft, it has a load capacity of 15.43 lb. and attains travel speeds up to 2.5mm/sec. Applications include photonic alignment, wafer inspection, vertical alignment, laser marking, optical positioning, testing, inspection, assembly and sampling.
Optimal Engineering Systems, Inc.; www.oesincorp.com
